Hefei Maniron HM-MNL-4-5-4M 5 W RF Termination Load
Hefei Maniron HM-MNL-4-5-4M 5 W RF Termination Load is backordered and will ship as soon as it is back in stock.
Manufacturer-published specifications
Every value below is traceable to the manufacturer's own published material for this order code. Where a figure is not published, the row is left out rather than estimated or borrowed from a similar model.
A 50 Ω termination load rated 5 W with a 4.3-10 male connector, covering DC–3800 MHz. Fitted to an unused port on a splitter, coupler or combiner so the port stays matched instead of reflecting power back into the network.
Part number note: Maniron's own catalogue number for this item is MNT-5-4G-4M. Specifications below are from that listing.
-
Part number
-
Ingress protection
-
Min operating temp (°C)
-
Max operating temp (°C)
-
Radio bands and standardsDC - 3800 MHz
-
ConnectivityPassive RF (no radio)
-
RF performance50 Ω, VSWR ≤1.1, Power 5 W
-
Network and serial interfaces4.3-10 male
-
Ports and connectors4.3-10
