Hefei Maniron HM-MLA-6-4M/F-E Lightning Arrestor with Earth
Hefei Maniron HM-MLA-6-4M/F-E Lightning Arrestor with Earth is backordered and will ship as soon as it is back in stock.
Australian compliance
Australian compliance
Certifications are listed only where the manufacturer states them against this order code. RCM is never assumed. If an approval matters for your project, ask us and we will confirm it in writing with the factory before you specify it.
Ordering and freight
Ordering and freight
Prices are ex-GST. GST and freight are calculated at checkout. If your organisation raises purchase orders, add the PO number to the cart note and it will come through with the order.
Hefei Maniron HM-MLA-6-4M/F-E Lightning Arrestor with Earth
Hefei Maniron HM-MLA-6-4M/F-E Lightning Arrestor with Earth is backordered and will ship as soon as it is back in stock.
Manufacturer-published specifications
Every value below is traceable to the manufacturer's own published material for this order code. Where a figure is not published, the row is left out rather than estimated or borrowed from a similar model.
A gas-discharge-tube coaxial surge arrestor covering DC–6 GHz, 4.3-10 male to female with an earth terminal. Fitted where the antenna feed enters the building or cabinet, so a lightning-induced surge goes to ground instead of into the router, BTS or repeater.
Rated for 10 kA discharge current (8/20 µs) with a 200 V limiting voltage. IP20 as supplied; IP67 with the buckle head fitted.
Note: Maniron's page lists two different maximum power figures for this part. We have not published a power rating rather than guess which is correct — ask us if it matters for your application.
-
Part number
-
Ingress protection
-
Radio bands and standardsDC - 6 GHz
-
ConnectivityPassive RF (no radio)
-
RF performanceInsertion loss 0.5 dB, VSWR 1.35, Max discharge current 10 kA (8/20 µs), Limiting voltage 200 V, Gas discharge tube
-
Network and serial interfaces4.3-10 male, 4.3-10 female, Earth / ground terminal
-
Ports and connectors4.3-10
Prices are ex-GST. GST and freight are calculated at checkout.
Blank fields are deliberate. We publish the manufacturer's own figures and leave the rest out. If you need a value that isn't here, ask and we will get it from the factory rather than guess it.
Some lines are enquiry-only. Where an order code or an approval needs confirming before we sell it into Australia, the page carries a request-a-quote path instead of an add-to-cart button.
Purchase orders are welcome. Add your PO number to the cart note and it travels with the order.
